Detail Information

Capacity (Load):	1-10T	Lift Drive / Actuation:	Hand
Product Name:	Hydraulic Hand Pallet Truck	Color:	Yellow
Load Capacity:	2500kg-5000kg Hand Pallet Truck	Wheels:	Nylon
Max. Lifting Height:	200mm	Fork Length:	1150/1220mm
Handle:	3-position Handle	MOQ:	1set
Material:	Steel Hand Pallet Truck

Product Description

Specification

item	value
Capacity (Load)	1-10T
Place of Origin	China
Lift Drive / Actuation	Hand
Product name	Hydraulic Hand Pallet Truck
Color	Yellow
Load capacity	2500kg-5000kg Hand Pallet Truck
Wheels	Nylon
Max. Lifting Height	200mm
Fork Length	1150/1220mm
Certification	ISO9001
Handle	3-position Handle
MOQ	1set
Material	Steel Hand Pallet Truck

Specification

*SPECIFICATIONS OF HAND PALLET TRUCK*
Model		HF20	HF25	HF30	HF40
Capacity	kg	2000	2500	3000	1000
Fork dimensions	mm	160x230x1200	160X365X1200	160x365x1200	160x230x900
Wheel Type		Nylon wheel/ Polyurethane wheel /Ordinary rubber wheel,etc
Load wheel Size	mm	70x80	70X80	70x80	80x95
Steer wheel Size	mm	180x50	180X50	180x50	180x50
Min.fox height	mm	80	80	80	80
Max.fox height	mm	200	200	200	200
Overall length	mm	1100	1200	1200	1220
Overall width	mm	550	685	685	550
Overall height	mm	1220	1220	1220	1220
Packing measurement	mm	2300x550x650	2400X685X650	2400x685x650	2300x550x650
Net weight	kg	58/ 65.5	63.5 / 71	63.5 /71	48 / 57.5

Products Description

DF PUMP is the traditional hydraulic pump and has been sold in the market for years. The DF pump is solid. And it could controlled the falling speed.

AC pump is an integral pump, which is import from German, more reliable and firmer. Integrated spool has long service life, less fault and labor saving.

Handle of Hand Pallet Truck

The handle has 3 gear.

Shift the gear position to controlled the pallet truck .
The top gear is drop.
The middle gear is set.
The bottom gear is rise.

PU Wheel

PU Wheel is in suitable resistance. It's durable due to its iron core. Its red and PU wheel is mild for the group. Use for ceramic tiles, floor, epoxy resin etc.

Nylon wheel

Nylon wheel is low resistance. Its white, and the price is cheap. Due to its hard surface,it's easy to creat noise and dust.

Our Service

Qingdao Huading always treat after-sale service as important as sale. Nowadays more than 50 agents around the world can supply Qingdao huading professional after-sale service.
All the product of Qingdao Huading supplied with one year or 2000 working hours (which occurs first) period quality warranty.

Certifications

Company Profile

WHO WE ARE
Founded in 2006, Qingdao Huading, comprehensive supplier of logistic and storage products in China, including plastic pallets,plastic foldable pallet boxes, plastic moving boxes, plastic garbage dustbins and series of products.

WHAT WE DO
We not only offer top quality plastic logistics products,but also professional logistics and storage solutions.

ADVANTAGES
1. Independent R&D Center; always able to offer customized products
2. Factory manufacturing base covers area 90,500 m2
3. Rich production lines meet different and special request from users.
4. Special QC team and independent testing labs, quality is guaranteed
5. Quick response on customers' request, one hour quick response in work day
6. On time shipping and order tracking
7. 7*24 hours after sale service

FAQ

1.Is your product customized?
Thanks for your question. Yes, because the working condition are different, all our products are customized dependingon detail
requirement! So if you give us more information about the lift capacity, span, lift height, power source and other specials, we
will give you a very quick quote!

2. What’s the information should I provide when inquiry?
Thanks for your question. The more information you provide, the accurate solution we can prepare for you! The information such as
the lift capacity, span, lift height, or other specials you give us will be more appreciated.

3. How many operating methods for my selection?
Thanks for your question. The standard operating methods we provide is pendent controller with push buttons. Meanwhile, we can
also provide the remote control with push buttons and the cabin (space capsule seat) control with joystick. You can choose any of
them, just tell us!

4.The space of my workshop is limited, can the crane ok for mine?
Thanks for your question. For low headroom workshop, we have the Special products. The detail dimension please consult our
professional engineer.

5. What’s the information should I provide when inquiry?
a. What's the lifting material?
b. How much is the maximum lifting weight of the hoist?
c. Have you installed the rails? Do you need us supply the rails? How long is it?
d. Where are the working environment?
